Platinum Cured Silicone Sleeves

Food/Pharma Tubings

WESTOSLEEVE™

Introduction

WESTOSLEEVE™

PLATINUM CURED SILICONE SLEEVES

Westosleeve™ is a range of highly durable TPE (Santoprene ™) tubings by Western Rubbers. These tubings are used heavily in applications such as fluid & gas transmission, peristaltic pumps, sterile fill lines and transfer of ph solvents across industries such as pharma, dairy, food, virology laboratories and more.

Features

Products Benefits

Colour: Transparent
(can be customized to any other colour)

Non-reinforced

Very thin wall thickness

Can adjust to machine
vibrations

Odorless and tasteless

standard dimensions

Available Sizes

Part No.	ID (in)	ID (mm)	Wall Thickness	Coil Length
WS-001	1	25.4	1mm/2mm/3mm	1m – 4m
WS-002	2	50.8	1mm/2mm/3mm	1m – 4m
WS-003	3	76.2	1mm/2mm/3mm	1m – 4m
WS-004	4	101.6	1mm/2mm/3mm	1m – 4m
WS-005	5	127	1mm/2mm/3mm	1m – 4m
WS-006	6	152.4	1mm/2mm/3mm	1m – 4m
WS-007	7	177.8	1mm/2mm/3mm	1m – 4m
WS-008	8	203.2	1mm/2mm/3mm	1m – 4m
Search	Search	Search	Search	Search

* Standard Coil Length For All Tubes: 1M – 4M
** The above list mentions the standard sizes of Westosleeve™ Tubes available with us in-house. However, we can undertake customizations. The minimum quantity for customization orders will range anywhere between 100-500 meters, depending on the cross sectional dimension of the tube.

Technical Specifications

data Sheet

WESTOSLEEVE™	Platinum Cured Silicone Sleeves
Color	Transparent/Red/Orange/Blue/Green
Compession Set (%)	0.2
Dielectric Strength	31 kV/mm
Elongation (break %)	8
Gas Permeability	low
Hardness (Shore A)	60 Sh A (+/- 5)* \| 70 Sh A (+/- 5)*
Material	Platinum Cured Silicone

WESTOSLEEVE™	Platinum Cured Silicone Sleeves
Specific Gravity	1.13 – 1.17
Sterilization Methods	Gamma, autoclave, ETO (on request)
Temperature Range	-60 °C to 230 °C
Tensile Strength (psi)	1595
UV Resistance	Excellent
water Absorption	low

* Note: Standard hardness for Westosleeve™ Tube is 60 Sh A & 70 Sh A. However, tubes can be customized in 50 Sh A and 70 Sh A hardness as well as per client’s requirement

Bulk Orders

If you buy large volumes (between 100 – 500 meters) of Westosleeve™ Tubes,
Western Rubbers will pass on some production, cost and dispatch benefits to you like:

01

Customizing tube sizes to suit your specific application

02

Offering highly competitive pricing

03

Customizing coil lengths to fit your process; this in turn would eliminate on-site cutting and ensure the tube is ready for use

04

Packaging tubes to suit your needs – single bag, double bag or individually packed coil lengths

05

Custom printing with indelible ink for lot traceability

NOTE: The minimum order quantity for customization orders will range anywhere between 100-500 meters, depending upon the cross sectional dimention of the tube.
